Concrete Mixer with 270 Degrees Rotation

Basic Info.

Model NO.	LM-5800
Type	Concrete Mixer
Shotcrete Type	Semi-Dry
Machining Process	Hydraulic
Structure	Rotor Type
Productivity	240m²/h
Feeding Height	1400mm
Vibrating Amplitude	0.9mm
Certification	ISO9001: 2000, CE
Condition	New
Color	White
Model	4m3 Concrete Mixer
Machine Weight	9200kg
Speed	30km/H
Min Turning Radius	5m
Drum Rotation Speed	15r/M
Engine	Yuchai4105 with Turbo
Power	85kw
Transport Package	a 40hq Container
Specification	8200*2400*3550
Trademark	SHANYI
Origin	China
HS Code	8474310000
Production Capacity	15000unit\Year

Product Description

Product details:






Main Features:
1,Articulated steering with small turning radius and flexibility.
2,Enlarged water tank , Save time for adding water .Improve work efficiency.One tank of water can be used for mixing 3 cans of concrete.
3,With the forward dumping function, discharge faster and more thorough.
4,The hydraulic external water pumping system can quickly add water and has greater water absorption.
5,Flexible and convenient pilot control system
6,SHANYI concrete mixer truck is equipped with HD reverse image
7,Electric scale can improve mixing quality.
8,SHANYI concrete mixer truck is equipped with optional central air conditioning.

Diesel engine:
Total displacement cylinder number	3900ml--4 cylinder in line
Injection	Direct injection ,mechanical control
Cooling system	Liquid cooled,Dry air filter
Max torque	390nm@2800 r\ minute
Specifications:
Overall dimension	8200*2400*3550(mm)
Minimum turning radius	5(m)
Speed	30km/h
Machine weight	9200kg
Steering System: rear--wheel steering options:4--wheel steering
4*4 Four-wheel drive:
3 forward gears	2 reverse gears
The first gear: 0--7km\hour	0--7km\hour
The second gear: 7--20km\hour	7--20km\hour
The third gear: 20-25km\hour
Brake: Air-brake
Load
Drum Capacity:700L	Be filled with 6 times
Mixing And Discharging
Drum geometric capacity: 6100L	Drum rotation speed: 15r\minute
Concrete Production: 4.0cbm\tank
Maintenance filler	Fuel tank: 200L
Total capacity of hydraulic system: 240L	Machine oil: 16L
Packing details	1 unit/40'HQ
